Key Features:
Product Highlights:
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE802.3at, IEEE 802.3bt |
| Network Ports | 8 10/100/1000Mbps copper ports Shielded RJ-45, auto-negotiation, auto-MDI/MDI-X support 2 1000Mbps SFP port SFP supports standard SFP fiber transceiver installation |
| Network Cables | 10/100/1000Mbps Copper: Cat. 5, 5e, 6 or higher up to 100m 1000Mbps Fiber: MMF 50/125µm, 62.5/125µm, SMF 9/125µm |
| Power over Ethernet | IEEE 802.3af, IEEE 802.3at and IEEE 802.3bt standard PSE on Port 1, 3, 5, 7 Power delivery 90W max. at port output Power output voltage: 56VDC Total PoE power supply budget: 360W |
| PoE Protection | Incompliant PD detection, Disconnection, Over-current, Short-circuit, Under voltage |
| MAC Addresses | 8K |
| Buffer Memory | 256KB |
| LED Indication | Per unit: Power Per port: Speed/link/activity, PoE status Per SFP: Link/activity status |
| Power Input | IEC320 receptacle, Operating voltage range: +100 ~ 240VAC |
| Power Consumption | 13.2W max. (Full load without PoE) |
| Housing | Enclosed metal with fan |
| Dimension | 220 x 206 x 44 mm (WxDxH) |
| Mounting Support | 19” rack mountable |
| Environment | Operating Temperature: 0°C ~ 40°C Storage Temperature: -20°C ~ 70°C Relative Humidity: 10% ~ 90% non-condensing |
| Approval | FCC Class A, VCCI Class A, CE mark Class A, EN62368-1 safety |
